Chondrosarcoma
Diagnosis in short

Chondrosarcoma. H&E stain.

LM "abnormal cartilage": +/-high grade changes - nuclear atypia (nuclear clearing, nucleoli, hyperchromasia), low/intermediate grade changes - bi-nucleation, hypochromatic enlarged nuclei, infiltration of lamellar bone ("invasion"), increased cellularity, irregular spacing of chondrocytes
Subtypes chondrosarcoma not otherwise specified (NOS), juxtacortical chondrosarcoma, myxoid chondrosarcoma, mesenchymal chondrosarcoma, clear cell chondrosarcoma, dedifferentiated chondrosarcoma
LM DDx chondroblastic osteosarcoma, enchondroma (esp. for low-grade chondrosarcoma), chordoma, others
Molecular t(9;22) for extraskeletal myxoid chondrosarcoma
Gross cartilaginous appearance
Site hip, shoulder, soft tissue, others

Syndromes Olier disease, Maffucci syndrome

Clinical history adults
Signs mass lesion
Prevalence uncommon
Prognosis good ~75% five year survival
Clin. DDx enchondroma, bone tumours, soft tissue lesions
Treatment excision

Chondrosarcoma is a malignant tumour of cartilage. It is in the chondro-osseous grouping of tumours and can be lumped into the much large category of the soft tissue lesions.

General

  • Usually a good prognosis - 75% five year survival in one large data set.[1]
    • Subtypes vary substantially - chondrosarcoma NOS and myxoid chondrosarcoma have a five year survival of ~70%, but mesenchymal chondrosarcoma only ~50%, and dedifferentiated chondrosarcoma an abysmal ~0%![2]
  • Grade and stage are independent predictors of survival.[2]

Clinical/epidemiologic features:[3]

  • Usually arise in a (benign) abnormality of cartilage (e.g. osteochondroma, enchondroma).
  • May be associated with a syndrome:

Subtypes

Several subtypes and their relative prevalence:[2]

  • Chondrosarcoma not otherwise specified (NOS) ~83% of cases.
  • Juxtacortical chondrosarcoma <1% of cases.
  • Myxoid chondrosarcoma ~10% of cases.
  • Mesenchymal chondrosarcoma ~4% of cases.
  • Clear cell chondrosarcoma <1% of cases
  • Dedifferentiated chondrosarcoma ~1% of cases.

Gross

  • Appendicular skeleton ~45% of cases.[2]
    • Classically hip.
  • Axial skeleton ~30% of cases.
  • Soft tissue ~10% of cases.

Note:

  • Peripheral chondrosarcoma are very rare.[4]
  • Chondrosarcoma is the most common primary malignant chest wall lesion.[5]
    • The classical location is anterior (costochondral arches or sternum), where it is more common than chondroma.

Microscopic

Features:[6][7]

  • "Abnormal cartilage":
    • +/-Nuclear atypia - high grade lesions.
      • High grade lesions:
        • Nuclear clearing.
        • Nucleoli.
        • Hyperchromasia.
      • Low/intermediate grade lesions:
        • Bi-nucleation.
        • Hypochromatic enlarged nuclei.
        • Infiltration of lamellar bone ("invasion") - not common - diagnostic.
    • Increased cellularity.
      • More cellular than cartilage... but relatively paucicellular compared to other sarcomas.
    • Irregular spacing of chondrocytes.

Notes:

  • Low grade chondrosarcoma are not cytologically malignant; the diagnosis rests mostly on radiologic findings.
    • The exception is infiltration of lamellar bone -- this is diagnostic of chondrosarcoma.[8]

DDx:

Images

www:

Variants

Mesenchymal chondrosarcoma

Myxoid chondrosarcoma

Microscopic: Features:

  • Chordoma-like:
    • Myxoid background.
    • Small cells with eosinophilic cytoplasm.

DDx:

Images:

  • Pathology outlines [1]
  • Pathology outlines [2]

Clear cell chondrosarcoma

  • Rare variant of chondrosarcoma (1.6%–5.4% of all chondrosarcomas)
  • Usually a low-grade malignant tumour[11]
  • Younger age than conventional chondrosarcoma
  • Teens to 40s; more common in males
  • Epiphyses of long tubular bones; proximal femur or humerus
  • Rarely head and neck [12]
  • Malignant counterpart of chondroblastoma?

Microscopic findings

  • Lobules of uniform to polymorphic densely-packed large cells
  • Well defined pushing borders
  • Clear to intensively acidophilic granular cytoplasm cytoplasm with vacuoles
  • Central nuclei with occasional prominent nucleoli
  • Low mitotic rate
  • Clear cell areas lack production of hyaline chondroid matrix
  • Areas with osteoclast-type giant cells mixed with small trabeculae of reactive bone
  • May contain conventional low-grade chondrosarcoma
  • May have secondary aneurysmal bone cyst changes
  • Pathology outlines [3]
  • Pathology outlines [4]
  • Pathology outlines [5]
  • Tumor library [6]
  • Tumor library [7]

DDX:

  • Chondroblastoma
  • Giant cell tumour of bone
  • Osteoblastic tumours
  • Metastatic clear cell renal cell carcinoma

Outside sources: E-immunohistochemistry[8]

Extraskeletal myxoid chondrosarcoma

  • Originally thought to be a variant of myxoid chondrosarcoma of bone; however, may not be a chondrosarcoma at all.[13]
  • Characteristic chromosomal translocation: t(9;22) CHN-EWS.

DDx:

  • Chordoma.[13]
    • S-100 +ve (strong).
    • EMA +ve.
  • Myxoid liposarcoma.

Image:

Dedifferentiated chondrosarcoma

Clinical:

  • Abysmal to poor prognosis.
    • In one series (22 patients) 5-year survival ~20%.[15]
    • All dead in two years in another series (25 patients).[16]

Features:[16]

  1. Poorly differentiated (mesenchymal) malignancy.
  2. Well-differentiated cartilaginous component.

DDx:

Images:

Grading

Features:[17]

  • Grade I: mild-to-moderate increase of cellularity +/- binucleated cells.
  • Grade II: between Grade I and Grade III.
  • Grade III: nuclear pleomorphism, mitoses common.

IHC

  • S-100 positive
  • Keratin negative
  • Collagen II positive
